Important Instructions
For your own safety read the following instructions carefully before attempting to connect this unit to the mains supply.
MAINS (AC) OPERATION
The wires in the mains lead are coloured in accordance with the following code :
GREEN
&
YELLOW
(Earth)
(if there is earth cable)
FUSE
BROWN
(Live)
BLUE
(Neutral)
IMPORTANT
As the colours of the wires in the mains lead of this appliance may not correspond with the coloured markings
identifying the terminals in your plug, proceed as follows:
The wire which is coloured green and yellow must be connected to the terminal which is marked with the letter E,
or by the earth symbol, or coloured green or green and yellow.
The wire which is coloured blue or black must be connected to the terminal which is marked with the letter N or
coloured Black.
The wire which is coloured brown or red must be connected to the terminal which is marked with the letter L or
coloured Red.
For continued protection against risk of re, replace only with same type and rating of fuse (ASTA approved 5A
250VAC fuse).
CAUTION
TO PREVENT ELECTRIC SHOCK DISCONNECT FROM THE MAINS BEFORE REMOVING COVER. NO USER
SERVICEABLE PARTS INSIDE. REFER SERVICING TO QUALIFIED SERVICE PERSONNEL.
SAFETY PRECAUTION
THIS EQUIPMENT MUST BE DISCONNECTED FROM THE MAINS WHEN NOT IN USE. DO NOT ALLOW THIS
UNIT TO BE EXPOSED TO RAIN OR MOISTURE.
English - 34 -
VESA WALL MOUNT MEASUREMENTS
He e
Sizes (mm)
WH
200 200
Se Siz
es
eth (X)
min. (mm) 10
max. (mm) 13
he () M6
Hereby, VESTEL Elektronik Sanayi ve Ticaret A.., declares that the radio equipment type TFT
IDTV is in compliance with Directive 2014/53/EU. The full text of the EU declaration of conformity is
available at the following internet address: doc.vosshub.com
