Polycom SoundPoint IP 450 Quick Tip

Quick Tip
SoundPoint ® IP, SIP 3.1.0
2
SoundPoint IP Phone Terminology
Before you read this document, it is important to understand the following
phone-related terminology:
• Attendant phone—The phone you use to monitor a remote line. The
phone has optional Expansion Modules and is set up to monitor one or
more remote lines using the BLF feature.
• Remote line—The remote line the attendant phone monitors.
• Idle state—The phone is “on hook” and there are no active, held, or
incoming calls.
• Active state—There is an active call in progress.
• Alerting state—There is an incoming call (the phone is ringing, if
configured with a ring tone).
• Call waiting state—There is an active call in progress and the phone is
ringing. (There may be held calls also.)
• Directed call pickup—You can answer an incoming call on a remote line.
The following figure shows a SoundPoint IP 650 and the parts of the phone
that are mentioned in this quick tip.

Polycom SoundPoint IP 450 Specifications

Display

display resolution	256 x 116 pixels
display type	backlit grayscale graphical LCD
display backlight	LED backlight with custom intensity control

Audio Features

frequency response	150Hz - 7kHz
codecs	G.722, G.711 μ/A, G.729A, iLBC
full-duplex speakerphone	Type 1 compliant with IEEE 1329

Power

power over ethernet	IEEE 802.3af Class 2
external AC adapter	24VDC/12W
power adapter	Universal, auto-sensing

Operating Environment

operating temperature	0 to 40°C (+32 to 104°F)
storage temperature	-40 to +70°C (-40 to +160°F)
relative humidity	5% to 95%, noncondensing

Size and Weight

dimensions	8.5 x 6 x 6.5 in x 2.5 in (21.5 x 15 x 16.5 x 6.5 cm)
box dimensions	12.5 x 13.25 x 3.5 in (31.75 x 33.5 x 9 cm)
unit weight	2.4 lbs (1.1 kg)
