Polycom
®
SoundStation
®
IP 7000 Conference Phone
Features and Specifications
www.polycom.com
Polycom Headquarters Polycom EMEA Polycom Asia Pacific
4750 Willow Road 270 Bath Road 8 Shenton Way
Pleasanton, CA 94588 Slough #11-01 Temasek Tower
1.800.POLYCOM or Berkshire SL1 4DX Singapore 068811
+1.925.924.6000 +44 (0)1753 723000 +65.6389.9200
Part No. 3726-47256-001 Rev 02/18/09
Additional SoundStation IP 7000 features/benefits
Equipped with built-in Power over Ethernet (PoE). An optional A/C power kit also available.•
20-foot microphone pickup, and even more with optional expansion microphones or multi-unit connectivity, reaching all corners of the room.•
Automatic Gain Control intelligently adjusts the microphone sensitivity based on where participants are seated in the conference room. •
Features technology that resists interference from mobile phones and other wireless devices, delivering clear communications without distractions.•
Built-in 2.5mm applications port allows you to connect the conference phone to a mobile phone for productive calls even where no network •
connection is available, or to a computer for calls using PC-based soft phone clients.
Power
IEEE 802.3af Power over Ethernet (built in)•
Optional external universal AC power supply:1•
00-240V, 1.5A, 48V/50W•
Display
Size (pixels): 255 x 128 (W x H)•
White LED backlight with custom intensity control •
Keypad
Standard 12-key keypad•
Context-dependent soft keys: 4•
On-hook/Off-hook, redial, mute, volume up/down•
Directional navigation wheel•
Audio Features
Loudspeaker•
Frequency: 160-22,000 Hz -
Volume: Adjustable to 85 dB at 1/2 meter peak -
volume
Full-duplex: Type 1 compliant with IEEE 1329 full •
duplex standards
Individual volume settings with visual feedback for •
each audio path
Voice activity detection•
Comfort noise fill•
DTMF tone generation / DTMF event RTP payload•
Low-delay audio packet transmission•
Adaptive jitter buffers•
Packet loss concealment•
Acoustic echo cancellation•
Background noise suppression•
Supported Codecs•
G.711 (A-law and Mu-law) -
G.729a (Annex B) -
G.722, G.722.1 -
G.722.1C -
Siren 14 -
Siren 22 -
Call Handling Features -
Shared call / bridged line appearance•
Busy Lamp Field (BLF)•
Distinctive incoming call treatment / call waiting•
Call timer•
Call transfer, hold, divert (forward), pickup•
Called, calling, connected party information•
Local three-way conferencing•
One-touch speed dial, redial•
Call waiting•
Remote missed call notification•
Automatic off-hook call placement•
Do not disturb function•
Other Features
Local feature-rich GUI•
Time and date display•
User-configurable contact directory and call •
history (missed, placed, and received)
Customizable call progress tones•
Wave file support for call progress tones•
Unicode UTF-8 character support. Multilingual •
user interface encompassing Chinese, Danish,
Dutch, English (Canada / US / UK), French,
German, Italian, Japanese, Korean, Norwegian,
Portuguese, Russian, Spanish, Swedish
Network and Provisioning
Ethernet 10/100 Base-T•
2.5mm connection port•
USB ports: Mini and regular USB 1.1 (not active •
at launch)
EX mic ports: Two Walta ports•
IP Address Configuration: DHCP and Static IP•
Time synchronization with SNTP server•
FTP / TFTP / HTTP / HTTPS server-based •
central provisioning for mass deployments.
provisioning server redundancy supported.
Web portal for individual unit configuration•
QoS Support -- IEEE 802.1p/Q tagging (VLAN), •
Layer 3 TOS and DSCP
Network Address Translation (NAT) support - static•
RTCP support (RFC 1889)•
Event logging•
Local digit map•
Hardware diagnostics•
Status and statistics•
User selectable ringer tones•
Convenient volume adjustment keys•
Field upgradeable•
Security
Transport Layer Security (TLS)•
Encrypted configuration files•
Digest authentication•
Password login•
Support for URL syntax with password for boot server•
HTTPS secure provisioning•
Support for signed software executables•
Safety
UL1950•
CE Mark•
CSA C22.2, No 60950•
EN60950•
IEC60950•
AS/NZSS3260•
EMC
FCC (47 CFR Part 15) Class B•
ICES-003 Class•
EN55022 Class B•
CISPR22 Class B•
AS/NZS 3548 Class B•
VCCI Class B•
EN61000-3-2; EN61000-3-3•
EN55024•
ROHS compliant•
Protocol Support
IETF SIP (RFC 3261 and companion RFCs)t•
IEEE 802.3af Power over Ethernet version
ships with
Telephone Console•
25 foot Ethernet cable•
Quick Start Guide•
Quick User Guide •
AC Power version ships with
Telephone Console•
25 foot Ethernet cable•
Universal Power Supply•
7 foot region-specific power cord•
Power Insertion Cable•
Quick Start Guide•
Quick User Guide•
HDX Ready version ships with
Telephone Console•
25 foot Ethernet cable•
15 foot C-link cable for connection to HDX•
Quick Start Guide•
Quick User Guide•
Environmental Conditions
Operating temperature: 32 - 104 degrees F (0 - •
40 degrees C)
Relative humidity: 20%-85% (noncondensing)•
Storage temperature: -22 - 131 degrees F (-30 - •
55 degrees C)
Warranty
1 year •
Country of Origin
China•
Phone Dimensions
15.5 x 14.6 x 2.9 in (39.4 x 37.2 x 7.3 cm) (L x •
W x H)
Phone Console Weight
2.4 lb (1.08 kg) •
Box Dimensions
19.1 x 17.0 x 5.1 (48.4 x 43.3 x 13 cm) (L x W •
x H)
Box Weight
5.4 lb (2.43 kg)•
©2009 Polycom, Inc. All rights reserved.
Polycom and the Polycom logo design are registered trademarks of Polycom, Inc. in the U.S. and various countries.
All other trademarks are the property of their respective owners. Information in this document is subject to change without notice.
