Specifications
3 - 3
System
• Frequency response: 20-22,000 Hz, + 0.1 /- 0.3 dB
• Idle channel noise: <-109 dB FS no weighting, 20-20,000 Hz, -60dB FS, 997
Hz input signal, 0 dB gain
• Dynamic range: >109 dB FS no weighting, 20 - 20,000 Hz, -60 dB FS, 997
Hz input signal, 0 dB gain
• Linearity: 0 dB FS to -122 dB FS +/- 1 dB
• THD+N: < 0.005%, -20 dB FS input signal
• Common mode rejection ratio: <-61 dB, 20-20,000 Hz, no weighting
• Cross talk: <-110 dB, 20-20,000 Hz, 1kHz, channel-to-channel
• Latency: Mic/Line inputs to outputs: 20 ms, AEC and NC processing
enabled
• Acoustic echo cancellation span: 200 ms
• Total cancellation: >65 dB
• Convergence rate: 40 dB/second
• Noise cancellation: 0-20 dB, software selectable
• Control inputs: contact closure
• Status outputs: open collector 60 V and 500 mA maximum total per
outputs
• All signal ground pins connected to chassis ground through low
impedance planes
Telco
• Input gain: -100 to +20 dB in 1 dB steps, software adjustable
• Nominal transmit level: 0 dBu in SoundStructure device yields -15 to -17
dBm to phone (country code dependent)
• Off hook loop current: 10 mA (minimum) to 120 mA (maximum)
• Output gain: -100 to +20 dB in 1 dB steps, software adjustable
• Frequency response: 250-3300 Hz
• Dynamic range: >70 dB FS, 250-3300 Hz, "A" weighted
Warning
Unless noted, all values are valid for all channels at 0 dB input gain.
