LCD MENU STRUCTURE
VORTEX EF2211/EF2210 Reference Manual 28 Technical Support: 800.932.2774
S
YSTEM
M
ENU
The SYSTEM menu contains POWER ON PRESET, ACKNOWLEDGEMENT MODE, BUS
R
EFERENCE, ERROR MESSAGES, FRONT PANEL LOCK, FRONT PANEL PASSWORD,
D
EVICE ID, BAUD RATE, FLOW CONTROL, LCD CONTRAST, METER, NON-VOLATILE
M
EMORY LOCK, NON-VOLATILE MEMORY PASSWORD, SCREEN SAVER, SOFTWARE
V
ERSION, and REBOOT EF2211/EF2210 configurations.
Power On Preset. Choose the EF2211/EF2210 Preset for power up.
Acknowledgement Mode. This command controls whether or not status
messages are sent.
EF Bus Reference. This designates which EF2211/EF2210 device, when
multiple devices are linked together, will put one of their echo canceller references on
the EF bus to be used as the EF bus reference.
Error Messages. Turns error messages On or Off.
Front Panel Lock. Locks or unlocks the front panel. When the front panel is
locked, you can see the parameters but you cannot change them.
The default passcode is aspi (case is important).
Front Panel Passcode. Once the device has been unlocked, the passcode
may be changed. At the F
RONT PANEL PASSCODE menu, press ENTER and then enter
a passcode and press E
NTER until you reach the end of the screen.
Device ID. Selects the Device ID of the unit.
Baud Rate. Selects baud rate of the RS-232.
Flow Control. Selects flow control between Hardware, None, or Auto.
Meter. Selects which signal is displayed on the front panel LED meter.
Non-Volatile Memory Lock. Controls the non-volatile lock feature.
When the non-volatile memory is locked, you can query the settings but will get an
error if you try to change them.
Non-Volatile Memory Password. This feature sets or queries the non-
volatile lock password. This password is used in conjunction with N
ON-VOLATILE
M
EMORY LOCK. The default password is aspi (case is important).
Screen Saver. Enables or disables the screen saver on the LCD panel. You can
also set the idle time.
Last Restored Preset. Displays the last restored Preset.
Software Version. Queries the software version.
Reboot EF2211/EF2210. Cycles power on the EF2211/EF2210.
Figure 15. EF2211/
EF2210 System sub-
menu
System
Power On Preset
Bus Reference
Error Messages
Acknowledgement
Mode
Front Panel Password
Device ID
Front Panel Lock
Non-Volatile
Memory Lock
Non-Volatile Mem
Password
Meter
Last Restored Preset
Reboot Vortex
Screen Saver
Baud Rate
Flow Control
Software Version
