PRE-INSTALLATION
VORTEX EF2211/EF2210 Reference Manual 4 Technical Support: 800.932.2774
P
RE
-I
NSTALLATION
What’s Included The Vortex EF2211/EF2210 product package includes the following items:
• Vortex EF2211/EF2210 Reference Manual
• Vortex EF2211/EF2210
• External power supply
• Cat 5 cable for EF Bus
• Telephone cable (NOT included with the EF2210)
• Rack mount screws (4)
• 3.5 mm terminal block connectors (6)
• Cable clamp and screw
• CDROM containing other manuals and Conference Composer software
• Product Registration Card
What’s Not
Included
The following equipment is not included with the EF2211/EF2210 product package,
but may be necessary to create a completely functional system:
• Microphones
• Loudspeakers
• Audio cables
• Videoconferencing codec or other four-wire interface (optional)
• RS-232 remote control device (optional)
Tools Needed for
Installation
• Screwdriver to mount the EF2211/EF2210 in your rack.
• 3.5 mm terminal block connector screwdriver
Figure 1. What’s Included with your Vortex EF2211/EF2210.
DOWN HOMEUP
0-3-7-12-20 3 dB
METER
920
PHONE CONNECT
ORTEXORTEXORTEXORTEXOR TEXOR TEXORTEXOR TEXOR TEXORTEXORTEXOR TEXOR TEXORTEXORTEXORTEX
ORTEXORTEXORTEXORTEXOR TEXORTEXORTEXOR TEXORTEXORTEXOR TEXORTEXORTEXOR TEXORTEXOR TEX
EF2211
Vortex
®
EF2211
Vortex
®
EF2210
Cable Clamp
and screw
1-Cat 5 cable
for EF
Bus
1-Telephone cable
External
Power Supply
OR
CD with
control software and manuals
Vortex EF2211/EF2210 Reference
Manual
Vortex
®
EF2211/EF2210
Reference Manual
Terminal Block
Connectors (6)
Rackmount
Screws (4)
x
x
x
x
