1. Set up the pool by following all instructions that come with the pool. Do not
fill water until the Filter Pump is properly installed. Locate the Outlet and
Inlet openings on the pool wall.
3. Install the return fitting on the Inlet opening of the pool.
8. Do not plug in the filter pump at this point. Begin to fill water until the water
level reaches the fill line.
2. Install the Suction Fitting on the outlet opening of the pool.
SETUP INSTRUCTIONS
4. Remove the Filter Pump , Hoses , and Hose Clamps from
the package.
9
1011
5. Connect the Hose 9 form the Suction Fitting 10 to the Filter Pump
Inlet.
6. Connect the Hose 9 form the pool Return Fitting to the Filter Pump
outlet.
7. Tighten all Hose Clamps 10 to prevent water leakage.
9. Air is now trapped inside the Filter Pump system, which will prevent the
water from flowing smoothly. To VENT the system (release the trapped
air), open the Vent Screw 12 at the top of the pump by turning it
counter-clockwise. The water pressure will force out all the trapped air
inside the Filter Pump system. Tighten the Vent Screw 12 when you see
water flowing out from the Seal Top 14 .
10. Adjust the Return Fitting Diverter 7 to maximize the circulation of the
pool water.
WARNING:
POSITION THIS PRODUCT AWAY FROM THE POOL, SO AS TO PREVENT CHILDREN FROM CLIMBING ON IT AND ACCESSING THE POOL.
Before assembling your product, please take a few minutes to check the contents and become familiar with all the parts.
9
10
11
9
10
7
6
1
4
4
3
1
2
Inlet
Outlet
7
360°
4
9
10
14
12
14
12
10 11
OWNER’S MANUAL
Should you encounter any problems, contact Customer Service at (844) 252-9983 from 8 AM to 5 PM Mon. thru Fri.
MST. Extended operating days and hours during peak season requirements.
Should you encounter any problems, contact Customer Service at (844) 252-9983 from 8 AM to 5 PM Mon. thru Fri.
MST. Extended operating days and hours during peak season requirements.
