- 32 -
Installation
Installation conditions
Installation place
The pool heat pump must be installed outdoors with more than 3,5m
distance of the pool according to the laws in force (NF C 15 100).
Installation of the pool heat pump should be on a flat, horizontal, and stable
surface. (Concrete base would be ideal).
Maintain 1 m space on the back (evaporator air inlet) and 3 m on the outlet
side of the fan.
Provide enough space in order to be able to have access to the temperature
controller.
Make sure that the discharged air will not be sucked into the evaporator
again.
To improve your installation
Avoid directing the flow of ventilated air towards a sensitive noise zone (room
window for example), or common areas for people (the discharged air will be
cold)
Avoid positioning pool heat pump on a surface that can transmit vibrations.
Try to avoid placing appliance under a tree or exposed to water or mud, which
would be likely to complicate performance and maintenance.
Inlet air flow:
1m
Outlet air flow:
3m
