- 34 -
Electrical connection
Electric supply voltage and current must correspond to the ones indicated on the
heat pump.
Connection cables have to be sized according to the appliance power and
installation requirements.
*Maximum cable length between heat pump and head of line protection
(D curve current protection)
These data are only given as reference; you must ask an electrician to determine
the exact data for your pool installation.
Power supply must be equipped with a 30 mA differential protection.
Use the cable glands and grommets provided inside the heat pump to route
cables.
As this machine is installed outdoors, connections must be made according to
corresponding standards (cable routed in protective conduct
with 50cm depth).
The heat pump only functions whenever there is water flow circulating inside
.
It is therefore imperative to maintain a minimum of water flow when the
heat pump is working. The working time of the heat pump depends directly
of the filtration system so that both should use the same electrical timer.
Maximum cable length* with diameter:
Model
Power
supply
Head of
line
protection
2,5 mm² 4 mm² 6 mm² 10 mm²
PAC 16 3 x 230 V
20 A 20 m 35 m 50 m 95 m
PAC 22 3 x 230 V
25 A - 25 m 35 m 65 m
PAC 31 3 x 230 V
32 A - - 30 m 45 m
PAC 31 5 x 400 V
3 x 16 A 100 m 150 m 200 m 300 m
