POMCube iCAN NetZero - Wiring Details; Power and Communication Cable Specifications

20
Table 5.4.1: Cable List
No.
Cable Specifaction
Connection
1
Power cable / Black /
1500mm/ 4AWG / 2 black
Surlok connectors
The bottom battery module B- to
BCMS module B-.
2
Power cable / Orange /
160mm/ 4AWG /2 orange
Surlok connectors
The top battery module B+
to BCMS module B+
3
Power cable / Orange /
190mm/ 4AWG / 1
orange & 1 black Surlok
connectors
Battery module B- to the next battery
module B+ below.
4
Power cable / Orange /
130mm/ 4AWG /2 orange
Surlok connectors
Solar controller B2+ to PCS B1+.
Solar controller B1+ to BCMS D+.
5
Power cable / Black /
130mm/ 4AWG /2
Black Surlok connectors
Solar controller B2- to PCS B1-.
Solar controller B1- to BCMS D-.
6
Communication cable /
Black / 190mm / Standard
8 way Ethernet cable/
RJ45 connectors
BCMS module Link Port to the top
battery module Link Port 0.
Battery module Link Port 1 to the next
battery module Link Port0 below.
7
Communication cable /
Black / 440mm / Standard
8 way Ethernet cable/
RJ45 connectors
EMS module RS485-2 to solar
controller RS485-LINK1
8
Communication cable /
Black / 350mm / Standard
8 way Ethernet
EMS module RS485-3 to
PCS module RS485-2
