POMCube iCAN NetZero - Specification

6
Management System) built-in.
(4) Multiple Working Modes
NetZero supports both on-grid and off-grid power systems.
(5) App Monitoring
You can monitor and control your NetZero anywhere by using the app.
(6) Intelligent Learning
NetZero is able to improve the strategy for you based on the learning of your
daily energy usage.
4.3 Specification
Table 4.3.1: Specification
Model No.
PNZ-BBS1
Battery Quantity
4
5
6
AC1 (Grid)
90-140Vac, 50/60±5Hz, Max. 63A
AC2 (Generator)
AC Load
5.0kVA, 50/60Hz, 110/120/127Vac
Overload Cap.:120% >3s, 150% >0.15s
Solar Controller
Input Voltage: 200-650Vdc
Max. Input Power: 6.6kW
Max. Charge Power: 5.0kW
MPPT Voltage
245-550Vdc
300-550Vdc
360-550Vdc
Capacity
(100%)*
1
44.8V90Ah
16.1kWh
20.2kWh
24.2kWh
51.2V90Ah
18.4kWh
23.0kWh
27.6kWh
Dimension
H*W*D: 1750*570*520mm / 70*22.5*20.5in
Weight*
2
265Kg/585lbs
313Kg/690lbs
360Kg/795lbs
Operating
Environment
Temperature: 41-104°F/5-40°C
Humidity: 10%-90% (No Condensation)
Origin
China
