POMCube iCAN NetZero - Install the Modules

18
Figure 5.2.4: Place and Mount the Rack
5.3 Install the Modules
(1) Put all the modules into the rack from the front side and then fasten them
with screws.
Figure 5.3.1: Install the Modules
Front Side is with Threaded
Holes on the Support Surface
Maintenance Space
Wall Mounting
Part, 2pcs
