POMCube iCAN NetZero - Internal Wiring Diagram

19
(2) Screw the Wi-Fi Antenna onto the connector as the figure shown.
Figure 5.3.2: Screw on the Wi-Fi Antenna
5.4 Internal Wiring
Connect the cables between the modules as the figure shown.
Figure 5.4.1: Internal Wiring Diagram
Wi-Fi Antenna
