Ponsel ACTEON 5000 - VB5 Sensor

12
Version 2.1
Update: April 2016
PONSEL Mesure – Aqualabo Contrôle
35 Rue Michel Marion – 56850 CAUDAN, FRANCE
Tel.: +33(0)2 97 89 25 30 – Fax: +33(0)2 97 76 55 72
2.2.7 VB5 sensor: Sludge Blanket detection.
The principle of measure is based on the mitigation of the Infra-Red signal in 870 nm through an
optical path of 5mm. The sensor delivers measures in Sludge Blanket detection in % of transmission
IR. For a better precision, the optics of the sensor are regulated in temperature.
Measurements
Measurement principle
Optical IR (870 nm) based on IR absorption
Range of measure
Sludge blanket : 0-100 %
Resolution
Sludge blanket : 0.01 à 0.1 %
Accuracy
Sludge blanket : +/- 2%
Response time
< 35 secondes
Temperature measure
Principle of measure
NTC
Working temperature
-5.00 °C to + 60,00°C
Resolution
0,01 °C
Accuracy
+/- 0.5 °C
Storage Temperature
-10°C to + 60°C
Degree of protection
IP 68
Singal Interface
Modbus RS-485 or SDI-12
Refreshment of the measure
Maximum < 1 seconde
Power supply
5 to 28 volts
Consumption
Standby : 25 µA (5 V)
Average RS485 (1 measure/seconde) : 4.5 mA (5V)
Average SDI12 (1 measure/seconde) : 4.5 mA (5V)
Curent Pulse : 100 mA during 30 mS
Heating times : 100 mS
Sensor
Weight
750 g (sensor)
Material
DELRIN, Nickel-plated brass, EPDM
Pressure max.
5 bars
Cable/ connexions
9-wire shielded conductor, uncoated-strand
polyurethane sleeve
Ingress protection rating
IP68
