Visit www.inverx.com.au for more information Page 17 of 23
3. Undo each tab, then remove the brush.
4. Take your new brush and insert the edge without the tabs under the brush holder. Ensure the brush is inside the
raised edges of the roller.
5. Pull the brush around the roller and fasten each connection tab. Pull on the end of each tab until its edges pass
through the slits.
3.4 Replacing Worn Track Belts
1. Ensure the robot is turned off and the magnetic safety cap is inserted underneath the robot.
