HANDLING
All units are shipped completely assembled. Care should be taken to avoid damage due to rough handling. If the unit is
not to be immediately installed, it must be protected from weather and site hazards.
CLEARANCE
For proper operation and service, PoolComPak™ Vertical, PoolComPak™ Horizontal and RoofPak units require 36”
clearance on all sides.
MOUNTING OF POOLCOMPAK UNITS
Locate the PoolComPak™ unit on a rm level base. If oor mounting, ensure that the oor is capable of supporting the
operating weight. If wall mounting or hanging a unit, provide a support structure that is capable of supporting the unit
while protecting pool patrons and employees from injury. Ensure that the support structure will not interfere with the
operation of the unit. Provision must be made for servicing units suspended above oor level. Install isolation pads under
the unit to minimize unit transmitted vibration noise.
INSPECTION
Upon receipt of the PoolComPak™ unit(s), immediately inspect for damage. In particular, inspect the housing and the
evaporator coil face. Minor indentations of the ns will not affect performance. However, if there is substantial damage,
immediately notify shipping company of unseen damage at delivery with a detailed letter outlining the damage. Retain
copies of all shipping damage claim documentation as well as photographs of the observed damage.
NOTE
PoolPak™ International does not ship damaged units from its facility nor is it
responsible for damage incurred during transit.
POWER SUPPLY
A separate fused disconnect switch must be provided per local codes and be within easy accessibility of the
PoolComPak™ unit. Use the minimum circuit capacity listed on the unit’s data plate to determine the minimum wire size
for incoming electrical power. The ground connection for the unit is located in the unit control panel. The power supply
to the unit must be adequate for the compressor starting amperage (LRA). If it is not, a compressor rotor stall will occur
during start-up due to an excessive voltage drop. All eld wiring must be done according to the wiring diagram provided
with the unit and in conformance to the National Electrical Code (NEC) and any other applicable local electrical code(s).
For Vertical and Horizontal PoolComPak™ units, installing contractor must punch a hole into the electrical compartment
to run power wires. The hole is to be properly nished with a rubber grommet and weather sealing.
CONTROL WIRING
All control wiring eld connections are described in the wiring diagram furnished with the PoolComPak™ unit as well
as in the Field Wiring section of this manual. All control wiring is low voltage.
CONDENSATE PIPING
The condensate may be piped to a drain or returned to the pool if local codes allow. If returned to the pool, the
condensate should be piped to the skimmer. PoolPak™ International recommends neither for, nor against, the practice
of returning condensate to the pool. The overow drain should be piped in a similar fashion. The installer should review
the local codes prior to making the decision of where to dispose of the condensate. The amount of condensate produced
in a year is about equal to the volume of the pool.
