25
PARTS LIST
I.D. Description Size Q’ty I.D. Description Size Q’ty I.D. Description Size Q’ty
X1RS ADJUSTING KNOB ASSEMBLY 1 X25Z FLAT WASHER 3/4 2 X40F GUARD STRONGER 1
X1V7 SPRING WASHER 5/16 16 X262 HEX. SCREW 3/4*2-1/2 1 X40G FRAME ARM COVER, LOWER 1
X1VV SCREW (CROSS HEAD) W/I WASHER 3/16*3/8 11 X263 HEX. SCREW 1/4*3/4 2 X40H FRAME ARM COVER, UPPER 1
X1W2 CROSS HEAD SCREW 3/16*1/4 3 X264 PULLEY 3 IN. Ø50-Ø76 1 X40J LOWER WHEEL 1
X1ZU STEEL BALL 1/4 1 X26C SPRING PIN 3*30L 1 X40K UPPER WHEEL 1
X21A POWER CORD STORAGE 2 X26L STAR KNOB M10 2 X40M LOWER DOOR 1
X21C HEX. FIXTURE BOLT 3/8 3 X26N HINGE UPPER 1 X40N UPPER DOOR 1
X21D CLIP HEAD 3 X26T KNOB 3/8 3 X40P UPPER COVER, INNER 1
X21F BRUSH HOLDER 1 X2D7 SCREW (CROSS HEAD) W/I WASHER 3/16*1/4 12 X40Q TRUNNION BRACKET 1
X21G STEEL PIN 2 X2D8 TABLE PIN 1 X40T PULLEY 7 IN. 1
X21H HEX. FIXTURE BOLT 2 X2DR HEX. SCREW 5/16*3” 1 X40V COMPLETED MOTOR W/CORD 1
X21K UPPER WHEEL SHAFT HINGE 1 X2JS CROSS HEAD SCREW M4*10L 1 X45M INSTRUCTION MANUAL 1
X21L SLIDING BKT. 1 X2NM BALL BEARING 2 X4AV FLAT WASHER 1/4*13 6
X21P PIN 1/4*16 4 X2PN PLASTIC BRUSH 1 X4AU SPRING PIN Ø6*20 1
X21Q PRESS SPRING 1 X2QG NYLON NUT 1/2 1 X56Z SCALE OF BLADE GUARD 1
X21R ADJUSTING SPRING 1 X2S2 SPRING WASHER 1/4 6 X570 WARNING LABEL 1
X21S ADJUSTING KNOB OF UPPER WHEEL 5/16*2L 1 X2SU PLATE 2 X571 WARNING LABEL 1
X21U STAR KNOB 5/16*1-1/4 1 X2U7 FLAT KEY 5*5*30 1 X574 NAMPLATE 1
X21Z TOOTH WASHER 5mm 2 X309 BALL BEARING 2 X575 TABLE INSERT 1
X221 FLAT WASHER 5/16*23 2 X348 STRAIN RELIEF BUSHING 2 X576 DUST COLLECTION HOSE 1
X224 FLAT WASHER 3/8*19 3 X39J RING 2 X577 HEX. BOLT 3/8*1-3/4 1
X225 FLAT WASHER 1/4*16 4 X3ZA SPRING WAHSER 3/16 3 X578 POWER CORD W/INSERT PLUG 1
X227 SPRING WASHER 3/4 1 X3ZB KNOB M6*18L 1 X579 BLADE GUARD, LOWER 1
X228 SQUARE NUT 3/8 1 X3ZF MOTOR LABEL 1 X57A GUIDE SUPPORT BRACKET BLADE GUARD 1
X229 BUTTERFLY NUT 5/16 1 X3ZH SHAFT OF LOWER WHEEL 1 X57B GUIDE POST (V TYPE) 243 MM 1
X22B HEX. NUT 3/4 1 X3ZJ SHAFT OF UPPER WHEEL 1 X57C UPPER ARM 1
X22C SET SCREW 5/16*5/16 1 X3ZL GUARD 1 X57D BASE 1
X22F SET SCREW M6*16L 2 X3ZM FLAT WASHER FOR LOWER WHEEL 1 X57E TABLE 1
X22H CROSS HEAD SCREW 3/16*3/8 2 X3ZN BEARING SHAFT 2
X22K CROSS HEAD SCREW 3/16*3/8 9 X3ZP BLADE GUIDE BLOCK 4 MOTOR PARTS
X22S BEARING COVER 1 X3ZQ Y TYPE GUIDE ACCESSORY 2 X1V8 SPRING WASHER 5 MM 2
X235 TRUNNION CLAMP SHOE 2 X3ZR LOWER GUIDE HOLDER 1 X21Z TOOTH WAHSER 5 MM 1
X238 TRUNNION 2 X3ZS POST SEAT (DOUBLE TEETH) 1 X23R SCREW (CROSS HEAD) W/I WASHER 3/16*1/4 1
X23A SCALE 1 X3ZT CUTTING BLADE
93-1/2*3/8
1 X25X COPPER WAHSER 1
X23B HINGE LOWER 1 X3ZV WHEEL PROTECTOR 2 X2D7 SCREW (CROSS HEAD) W/I WASHER 3/16*1/4 4
X23D POINTER 1 X3ZW MITER GAUGE ASSY. 1 X348 STRAIN RELIEF BUSHING 1
X23F SPRING PIN Ø3*10 1 X3ZZ C RING 2 X349 TERMINAL 2
X23G FLAT WASHER 5/16*18 12 X400 RING 1 X40Y CROSS HEAD SCREW 3/16*3/16 2
X23J HEX. NUT
5/16 5 X401 FLAT KEY 5*5*60 2 X411 CAPACITOR COAST 1
X23K HEX. NUT 3/16 5 X402 FLAT WASHER 3/8*16 1 X417 MOTOR WIRE 1
X23L HEX. NUT 1/2 1 X403 FLAT WASHER 3/8*25 1 X418 CAPACITOR 1
X23M HEX. SCREW 5/16*1-1/4 6 X404 FLAT WASHER 1/2*28 1 X41C CAPACITOR COVER 1
X23Q HEX. SCREW M10*50L 2 X405 MICRO ADJUSTING NUT M6 2 X41D WIRE COVER, LOWER 1
X23R CROSS HEAD SCREW W/I WASHER 3/16*1/4 2 X406 NUT 3/8 1 X41E WIRE COVER, UPPER 1
X240 HEX. WRENCH 3 MM 1 X407 SECTOR SCREW M6*10L 1
X241 HEX. SCREW 1/4*1/4 2 X408 SET SCREW M6*45L 2 HARDWARE BAG
X243 SPRING CLIPPER 3 X409 SCREW (HEADLESS) M6*10L 7 X4AW STAND ATTACHMENT HARDWARE BAG 1
X244 V-BELT 1 X40A HEX. SCREW 1/4*5/8 7 X2DJ SAWDUST PORT HARDWARE BAG 1
X247 CROSS HEAD SCREW W/WASHER 3/16*1/2 2 X40B HEX. SCREW 1/2*2” 1 X2DH TRUNNION SUPPORT HARDWARE BAG 1
X25X COPPER WASHER 2 X40C SAFETY SWITCH 1 X2DK
POWER CORD STORAGE HARDWARE BAG
1
X25Y WASHER 3/16-14 4 X40D BALL BEARING 2
14 IN. (355 MM) BAND SAW
PARTS LIST FOR BAND SAW
