KNOW YOUR BAND SAW
Lower blade
support bearing
Lower blade
guide
Upper blade
wheel
Blade guard
Upper blade
support bearing
Upper blade guide
Blade
Table insert
Table
Table removed for
clarity of illustration
Blade tension
knob
Blade tension
gauge
Blade tracking
knob
Power cord
storage
Motor cord
Stand top
plate
Cabinet stand
Table tilt stop bolt
Motor
Table trunnion
Table aligning pin
Upper
guide bar
Lower
blade
wheel
Table lock knob
Mounting holes
Sawdust port
Lower cover
Wheel brush
ON/OFF switch
Upper cover
Upper guide lock knob
Blade guide slide knob
Belt tension
bolt
Table tilt scale
