20
INTERIOR CUTTING (FIG. U)
1. Lay out the design on the workpiece (1). Drill a 1/4 in.
(6.4 mm) hole in the workpiece.
2. Lift the blade tension lever (2) and remove the blade
(3). Refer to BLADE REMOVAL AND INSTALLATION.
3. Place the workpiece on the table with the
workpiece hole (4) over the access hole in the
table (5).
4. Install the blade (3) through the hole in the workpiece
and press the blade tension lever (2).
5. Follow the process 3-8 under the section of
FREEHAND CUTTING.
6. When nish the cutting, turn the scroll saw OFF,
remove the blade from the blade holders and remove
the workpiece from the table.
Fig. U
1
4
2
3
5
