PFC-4064 KEYPAD PROGRAMMING • 8870080 • REV A • 12/17
11
To edit/rename an entry, select the eld you would like to change using the arrow keys as done when setting up the software
zones. Press “Enter” to open the eld. Once the eld is available, scroll through the available characters to nd the letter,
number, or special character desired using the Up/Down arrow keys. Move to the next character space using the left/right
arrow keys. When nished, press “Enter” to save changes before pressing “ESC”.
When selecting the order the points are listed in, the screen will allow you to change the number through either the up/down
arrow keys or by manually typing in the order number preferred. All single digit number selections must use a zero. It is
highly recommended that the assigned point name and number is written down to avoid confusion and programming errors.
When selecting a Point Function, use the up/down arrow keys to select a function for the notication or signaling circuit.
The options for the output (NAC) circuits are:
• City Tie
• Aux Door Holder Low AC (Aux D-Hold-AC)
• Aux Door Holder (Aux D-Hold)
• Aux Resettable
• Aux Constant
• Wheelock Sync
• System Sensor Sync (Sys Sensor)
• Gentex Sync w/T4
• Gentex Sync
• AMSECO Sync
• NAC Gen Purp
• Unused
Zone Name
NAC 1
Select Point:
Current: 1
Set: [1]
NAC 1
Point Function
Curr: NAC Gen Purp
Set: [City Tie ]
The options for the input circuits are:
• Smoke
• HVAC Restart
• Supervisory
• CO Alarm
• Lamp Test
• Disable Inputs/Outputs
• Disable Outputs
• Disable Inputs
• Fire Alarm
• Silence
• Reset
• Aux Input
• Trouble Monitor
• Fire Drill
• Tamper
• Waterow
• Pull Station
• Heat
• Unused
