PFC-4064 KEYPAD PROGRAMMING • 8870080 • REV A • 12/17
System Defaults: Relay Circuit
The PFC-4064 has a total of 4 built-in relays available for use. The relays (shown below) are located along the central bottom
edge of the control panel’s circuit board.
Relay Output Terminal Default Settings
Terminal # Activation Setting Type
1 Alarm
2 Supervisory
3 Waterow
4 Trouble
3
