Property Value Unit
Supply level 24 V DC
Signal level 24 V DC
Encoder signals Track 'A' and 'B' (shifted 90°)
Only handwheels with A/B signals can be used. No
'Pulse/Direction' signals are supported.
When these particular inputs are used for a handwheel, the soft-
ware of the control unit will only read the value of a hardware fast
counter implemented on the 2416 EL module which is counting the
track signals. This avoids counting errors that could occur if the
software was reading the tracks directly like standard I/Os.
Prerequisites for the described functionality of the handwheel
inputs:
n control unit software revision above 2.3.8
n special machine parameter settings
For further information refer to the machine parameter manual
or machine parameter tool (MPTOOL) online help.
Required Handwheel Specifications
Behavior
PA 8000 EL CNC control unit
Design and function
24.09.2015 | 35
