Fig. 13: Wiring schematic handwheel inputs

1 Handwheel

2 Input byte 3

3 Power supply connector

The ground of the power supply used for the hand-

wheel must be connected to the one of the power sup-

plies of the 2416 EL module (connector X30, pin 3).

Wiring Schematic

PA 8000 EL CNC control unit

Design and function

24.09.2015 | 36
