Power Electronics VS65 Series Programming And Software Manual

POWER ELECTRONICS
VS65 SERIES MV SOFT STARTER
PARAMETERS DESCRIPTION
25
E
N
G
L
I
S
H
Screen &
Default Value
Name /
Description
Range
Function
20 SHRPIN2=OFF
G8.20 / Dual
setting
Shearpin
current
(0.6 to 1.2)·In
of VS65,
OFF
The soft starter should stop immediately when the current drawn by the motor reaches this value
during nominal conditions. This parameter is off during acceleration or deceleration. The stop
should be done in a controlled way.
Set current value for the VS65 to stop.
Application: Oversized electrical motors used for starting, but working under nominal conditions
at running, it may only reach the Shearpin current due to mechanical problems like locked rotors,
etc.
21 ASYM I ENB2=N
G8.21 / Dual
setting
asymmetrical
current
Y
N
Enable/Disable the asymmetric current protection at the soft starter. When enabled, the soft
starter will trip on F3 ASYMMETRIC CURRENT if there is a current imbalance greater than 40%.
22 I MTR2=xxxxA
G8.22 / Dual
setting motor
rated current
1 to 1200A
Set the nominal current of the motor. This is necessary for correct motor protection.
Set this value according to rated (nameplate) motor current.
23 V MTR2=2
G8.23 / Dual
Setting rated
Motor Voltage
1 to 4
Set the work rated voltage
Depending on the line voltage, there are two versions of this parameter, one for voltages from
2300V to 6000V and another from 6600V to 13800V.
From 2300 to 6000V:
OPT.
DESCRIPTIÓN
1
2300V
2
3300V
3
4160V
4
6000V
From 6600 to 13800V:
OPT.
DESCRIPTIÓN
1
6600V
2
7200V
3
10000V
4
13800V
Introduce this parameter in accordance with the VS65 input line voltage. Make sure the motor
plate voltage is within the related voltage range.
24 P MTR 2 =40kW
G8.24 / Dual
setting motor
rated power
40 to
9990kW
Set the nominal motor power rating.
25 COS PHI 2 =85%
G8.25 / Dual
setting motor
power factor
40 to 99%
Set the rated (nameplate) motor cos phi to for calculating the instantaneous torque developed by
the motor.
26 FREQ 2= 50Hz
G8.26 / Dual
setting supply
frequency
50Hz
50/60Hz
Set the mains frequency.
Set as default setting, where the mains frequency is 50Hz. Where the mains frequency is
unknown or different than 50Hz (60Hz) set 50/60Hz.
Note: When you set 50/60Hz the VS65 starts an algorithm to detect the mains frequency. This
algorithm is off when setting 50Hz.
