Power Electronics VS65 Series Programming And Software Manual

POWER ELECTRONICS
VS65 SERIES MV SOFT STARTER
MODBUS COMMUNICATION
33
E
N
G
L
I
S
H
Parameter
Screen
Description
Address
Range
Modbus Range
G3.14
14 START LIMIT=3
Maximum Number of Starts
40042
1 to 10
1-10
G3.15
15 STR/INT=15Min
Start interval
40043
0 to 60Min, OFF
1-61
G4.1
1 STR DELAY=0s
Starting Delay
40045
0 to 600s
0-600
G4.2
2 PULS TORQ =50%
Torque Pulse
40046
50 to 100%
50-100
G4.3
3 PULS TQ T=OFF
Torque Pulse Time
40047
OFF,
0.1 to 0.9s
0-9
G4.4
INIT TORQ=35%
Initial Torque
40048
30 to 99%
35-99
G4.5
5 INIT TQ T=1s
Initial Torque Time
40049
0 to 10s
0-10
G4.6
6 ACEL TIME=6s
Acceleration Time
40050
0 to 180s
1-180
G4.7
7 I LIMIT=1400A
Current Limit
40051
(1.5 to 5)·In of VS65
300-1000
G5.1
1 FREWEL STP=Y
Freewheel Stop
40053
Y
N
0-1
G5.2
2 DECL TIME=12s
Deceleration Time
40054
1 to 180s
1-180
G5.3
3 DEC MD SEL=1
Motor Deceleration Algorithm
40055
1 to 2
1-2
G5.4
4 HAMR FACT=75%
Hammer Factor
40056
1 to 99%
-
G5.5
5 MINI TORQ=1%
Minimum Torque
40057
1 to 99%
-
G6.1
1 OPER MODE=1
Control Mode Source
40059
0 to 5
0-5
G6.2
2 LOCAL RESET=Y
Local Reset Control
40060
Y
N
0-1
G6.3
3 DINPUT1 SEL=4
Multifunction 1 input
40061
0 to 10
0-10
G6.4
4 DINPUT2 SEL=0
Multifunction 2 input
40062
0 to 10
0-10
G6.5
5 DINPUT3 SEL=0
Multifunction 3 input
40063
0 to 10
0-10
G6.6
6 DINPUT4 SEL=0
Multifunction 4 input
40064
0 to 10
0-10
G6.7
7 DINPUT5 SEL=0
Multifunction 5 input
40065
0 to 10
0-10
G6.8
8 ANI1 FORMAT =1
Analogue Input 1 Format
40066
0 to 2
0-2
G6.9
9 AI1 RANGE 0_10
Analogue Input 1 Range
40067
0_0 to 0_999
0-999
G6.10
10 AI1 UNITS=OFF
Analogue Input 1 Units
40068
OFF,
Bar
ºC
Mtr
0-3
G6.11
11 ANI2 FORMAT =1
Analogue Input 2 Format
40069
0 to 2
0-2
G6.12
12 AI2 RANGE 0_10
Analogue Input 2 Range
40070
0_0 to 0_999
0-999
G6.13
13 AI2 UNITS=OFF
Analogue Input 2 Units
40071
OFF,
Bar
ºC
Mtr
0-3
G7.1
1 REL1 SEL ON=14
Relay 1 control Source Selection
40073
0 to 21
0-21
G7.2
2 REL2 SEL ON=15
Relay 2 control Source Selection
40074
0 to 21
0-21
G7.3
3 REL3 SEL ON=9
Relay 3 control Source Selection
40075
0 to 21
0-21
G7.4
4 ANALOG1 SEL=0
Analogue Output 1 Source Selection
40076
0 to 7
0-7
G7.5
5 AO1 FORMAT=0
Analogue Output 1 Format
40077
0 to 1
0-1
G7.6
6 AO1 LOW=0%
Analogue Output 1 Low Set point
40078
0 to 500%
0-100
G7.7
7 AO1 HIGH=100%
Analogue Output 1 High Set point
40079
0 to 500%
100-500
G8.1
1 DUALSETING=N
Dual Setting
40081
Y
N
0-1
G8.2
2 PLS TORQ2=50%
Dual setting Torque Pulse
40082
50 to 100%
50-100
G8.3
3 PLS TQ T2=OFF
Dual Setting Pulse Time
40083
OFF,
0.1 to 0.9s
0-9
G8.4
4 INIT TRQ2 =30%
Dual Setting Initial Torque
40084
30 to 99%
30-99
G8.5
5 T PAR INI2=1s
Dual Setting Torque Time
40085
0 to 10s
0-10
G8.6
6 ACC TIME2=12s
Dual Setting Acceleration Time
40086
0 to 180s
1-180
G8.7
7 LTE INT2=2800A
Dual Setting Current Limit
40087
(1.5 a 5)·In del VS65
300-1000
G8.8
8 FREWEL STP2=N
Dual Setting Freewheel Stop
40088
SI
NO
0-1
G8.9
9 DEC TIME2=12s
Dual Setting Deceleration Time
40089
0 to 180s
1-180
G8.10
10 DEC MD SEL2= 1
Dual Setting Deceleration Mode Selection
40090
1 to 2
300-1000
G8.11
11 HAMR FAC2=75%
Dual Setting Hammer Factor
40091
1 to 99%
-
G8.12
12 MINI TRQ2=1%
Dual Setting Minimum Torque
40092
1 to 99%
-
G8.13
13 PHASE SEQ2=2
Dual Setting in phase sequence soft starter
input
40093
1 to 3
1-3
G8.14
14 OV LOAD2=InA
Dual Setting Overload Motor Current
40094
(0.6 to 1.5)·InVS65
120-300
G8.15
15 OV/LOAD T2=5
Dual Setting Overload Curve
40095
1 to 10
1-10
G8.16
16 OVL FAC2=100%
Dual Setting Starting Overload Factor
40096
100 to 500%
100-500
