CONFIGURATION TABLE & STANDARD RATINGS
MODELS VS65 4.16kV
CODE
NOMINAL
CURRENT (A)
MOTOR POWER
(kW) (HP) [3]
VS65050 4
50
298
400
VS65055 4
55
336
450
VS65060 4
60
373
500
VS65070 4
70
447
600
VS65080 4
80
522
700
VS65095 4
95
597
800
VS65110 4
110
671
900
VS651
20 4
120
746
1000
VS65150 4
150
932
1250
VS65180 4
180
1119
1500
VS65210 4
210
1305
1750
VS65240 4
240
1491
2000
VS65270 4
270
1678
2250
VS65300 4
300
1864
2500
VS65320 4
320
2051
2750
VS65350 4
350
2237
3000
VS65410 4
410
2610
3500
VS65470 4
470
2983
4000
VS65530 4
530
3356
4500
VS65590 4
590
3728
5000
VS65650 4
650
4101
5500
VS65700 4
700
4474
6000
[3] HP standard motor rated power (cos φ = 0.88, 4.16kV)
MODELS VS65 6kV – 6.6kV
CODE
NOMINAL
CURRENT (A)
MOTOR POWER
(kW) [4] (HP)
VS65040 6
40
400
536
VS65045 6
45
450
603
VS65050 6
50
500
671
VS65055 6
55
560
751
VS65060 6
60
630
845
VS65070 6
70
710
952
VS65080 6
80
800
1073
VS6
5090 6
90
900
1207
VS65100 6
100
1000
1341
VS65125 6
125
1250
1676
VS65140 6
140
1400
1877
VS65160 6
160
1600
2146
VS65180 6
180
1800
2414
VS65200 6
200
2000
2682
VS65220 6
220
2240
3004
VS65250 6
250
2500
3353
VS65280 6
280
2800
3755
VS65300 6
3
00
3150
4224
VS65350 6
350
3550
4761
VS65400 6
400
4000
5364
VS65450 6
450
4500
6035
VS65500 6
500
5000
6705
VS65560 6
560
5600
7510
VS65630 6
630
6300
8449
[4] kW standard motor rated power (cos φ = 0.88, 6.6kV)
MODELS VS65 10kV – 11kV
CODE
NOMINAL
CURRENT (A)
MOTOR POWER
(kW) [5] (HP)
VS65020 6
20
400
536
VS65025 6
25
450
603
VS65030 6
30
500
671
VS65035 6
35
560
751
VS65040 6
40
630
845
VS65050 6
50
710
952
VS65055 6
55
800
1073
VS6
5060 6
60
900
1207
VS65075 6
75
1000
1341
VS65085 6
85
1250
1676
VS65095 6 95 1400 1877
VS65110 6
110
1600
2146
VS65120 6
120
1800
2414
VS65135 6
135
2000
2682
VS65150 6
150
2240
3004
VS65170 6
170
2500
3353
VS65190 6 190 2800 3755
VS65210 6
210
3150
4224
VS65240 6
240
3550
4761
VS65270 6
270
4000
5364
VS65300 6
300
4500
6035
VS65340 6
340
5000
6705
VS65380 6 380 5600 7510
[5] kW standard motor rated power (cos φ = 0.88, 11kV)
