Power Electronics VS65 Series Hardware And Installation Manual

VS65 SERIES MV SOFT STAR
TER
POWER ELECTRONICS
16
TECHNICAL CHARACTERISTICS
GENERAL
FEATURES
Colour (Metal Parts)
RAL 7032
Corrosion Protection
C4
in accordance
with ISO 12944
-
2
Paint
ing
duration
H in accordance with ISO 12944
-
1
Input and output holes for cabling
Yes,
access from above
COMMUNICATION
Standard Hardware
RS232 / RS485
Optional Hardware
Ethernet
Standard Protocol
Modbus
-
RTU
Optional Prot
ocol
Profibus DP, Devicenet, Ethernet, N2 Metasys
Control modes
Local: from keyboard
Remote: from the digital and analogic inputs
PLC: start / stop
MOTOR
PROTECTIONS
Input phases sequence
High Voltage
Input Low Voltage
Start current limi
t
Rotor locked
Motor overload (thermal model)
Under load
Unbalanced phases
Shearpin current
Maximum number of starts/hour
SOFT STARTER
PROTECTIONS
SCR overheat
Excessive start time (max 120s)
Input phase loss
SOFT STARTER
SETTINGS
Torque pulse
Initial torque
Initial torque time
Acceleration time
Current limit: 1to 5·In
Overload: 0.8 to 1.2·In, Overload curve: 0 to 10
Deceleration time / Freewheel stop
Slow Speed(1/7 fundamental frequency)
Dual setting
Number of S
tarts/hour allowed
Torque control
Water hammer control stop
REGULATIONS
Certification
CE
Designed as
EMC Directive (2004/108/CE)
EN61000
-
6
-
2,
-
4
Design and construction
EN62271
-
1,
-
200
EN60071
-
1,
-
2

Power Electronics VS65 Series Specifications

General

Brand	Power Electronics
Model	VS65 Series
Category	Controller
Language	English
