Figure 6
Figure 7
Need help? Contact our Technical Support Team at 813.689.9932 option 2
TROUBLE
Shooting Guide
INSTALLATION of New Dash Switch Battery
1. Ensure the surrounding area is as dry as possible to avoid moisture intrusion.
2. Remove the (2) #8 x 3/4” flat head screws from the top of Dash Switch.
3. Use a small slotted screwdriver to remove the Dash Switch cover plate. (FIG. 6)
4. Remove the rubber switch membrane and the board from the Dash Switch base.
5. Remove the battery from the holder on the back of the board and replace with any CR2032 3V
Lithium Coin Battery.
6. Place the board and rubber switch membrane back into the Dash Switch base and ensure that
the rubber switch membrane is seated properly prior to installing the cover plate (FIG. 7)
SYMPTOM RECOMMENDATION
Slipping / noise when anchored
Reduce anchor force and retry.
Spike does not retract
Reduce the anchor force setting by one level
from the MICRO Driver Unit.
NOTE: If stuck down the force setting may
be too high.
Excessive slop / wobble when stowed
or deployed
Call our Technical Support Team at
1 + (813) 689-9932 option 2
Driver is making a grinding
noise while running
Flush spike pocket with water to remove any
dirt that could be causing the grinding noise
(FIG. 5)
16 | MICRO Installation & Owner’s Guide | www.power-pole.com
