MICRO Installation & Owner’s Guide 2018 | www.power-pole.com | 7
Attaching / Removing Driver Unit
Attach the MICRO Driver Unit into its mount as shown.
Next, push the release clamp bolt through and thread the
adjustable nut
K
on tight by turning clockwise and lock
quick release clamp into position.
Installing Quick Release Cord (for kayaks)
Lock the quick release clamp into a 90 degree position as
illustrated for quick release pull cord.
IMPORTANT: The quick release clamp handle must be
oriented as shown and the quick release
pull cord pulled towards the bow of
vessel to function properly.
Pull this way
to unlock
quick release
handle.
ATTACHING DRIVER Unit
Mark and drill a hole
with a 7/64” drill bit to
fasten the
S
cord holder
to vessel with
F
screw
where easily accessible
Fasten the end of
R
quick release pull cord to quick release clamp handle by tying them together using a knot.
K
L
L
J
J
R
F
S
