Powermate M-2C User Manual

MODEL M-1
REPLACEMENT COMPONENT LIST

PowerMate
®
Operation Manua
l
PARTS LIST
DESCRIPTION
PART ITEM
STRAPBAR MS400080S
1
BATTERY 12V 32Ah SEALED051310C
2
SCREW ASSEMBLY M-1, M-2B300550C
3
ELECTRIC MOTOR
050860D4
SOLID STATE CONTROLLER
052810
5
RUBBER GUARD ASSEMBLY
4002306
MOTOR GUARD
305770
7
SPLASH GUARD
3057718
BUZZER ASSEMBLY
3015229
SWITCH PUSH BUTTON 2 TERMINAL
05021010
AXLE30782011
WASHER 3/4 SAE
05006012
WHEE 8"30132013
COTTER PIN 1/8 x 1 ZINC
05011014
BOTTOM FELT
10140015
FELT TOP
10141016
WHEEL CASTER
05133017
DOLLY ATTACHMENT
30581018
INNER FRAME300010D19
OUTER FRAME300020C
20
TOP GUARD
10232021
STEEL ROLLER WHEEL
05297022
HOOK BAR
30073323
BATTERY COVER BOTTOM
30601024
BATTERY COVER TOP306000C
25
CIRCUIT BREAKER 100A
05136426
FUSE 10 AMP AGC
05170527
FUSE HOLDER
052690B28
CHARGE PLUG
301393A29
GASKET - CIRCUIT BREAKER
05142530
BATTERY TERMINAL COVER LH MS
05131131
BATTERY TERMINAL COVER RH MS
05131232
PN 010500 Rev.E1
Eng. 03/ 31/ 16
Sheet 1 of 2
4.01
16
11
15
12 13 12 17 18
23
111422
5
984
7
6
24
2
31
32
29
25
30
26
28
27
10
19
21
3
20
