Powermate M-2C User Manual

MODEL M-1 with BATTERY SWITCH
REPLACEMENT COMPONENT LIST

PowerMate
®
Operation Manua
l
PARTS LIST
DESCRIPTION
PART No.ITEM
SCREW GUARD BACK
3025001
SCREW GUARD FRONT
3025102
SCREW COVER
3026103
ROLLER GUARD
3026404
BATTERY 12V 32Ah SEALED051310C
5
MOTOR GUARD
3057706
BOTTOM RUBBER GUARD
4002307
SPLASH GUARD
3057718
SOLID STATE CONTROLLER
0528109
BUZZER ASSEMBLY
30152210
SCREW ASSEMBLY M-1, M-2B300550C
11
SWITCH PUSH BUTTON 2 TERMINAL
05021012
BOTTOM WHEEL AXLE M-1 PF
30782013
WASHER 3/4 SAE
05006014
WHEEL 8"30132015
COTTER PIN 1/8 x 1
05011016
DOLLY ATTACHMENT MS
30581017
WHEEL CASTER 3" SWIVEL
05133018
BOTTOM FELT
10140019
FELT TOP
10141020
STEEL ROLLER WHEEL
05297021
OUTER FRAME300020C
22
TOP GUARD
10232023
HOOK BAR
30073324
INNER FRAME300010D25
ELECTRIC MOTOR050860D26
BATTERY TERMINAL COVER LH05131127
BATTERY TERMINAL COVER RH05131228
BATTERY COVER TOP306005B29
BATTERY COVER BOTTOM30601030
SWITCH BOX MS30555031
SWITCH BATTERY DISCONNECT051362A32
CIRCUIT BREAKER 100A05136433
GASKET - CIRCUIT BREAKER05142534
FUSE HOLDER052690B35
FUSE 10 AMP AGC05170536
CHARGE PLUG ASSEMBLY MS301393A37
STRAPBAR M-SERIES400080A38
PN 010500E1 EC
Eng. 03/ 31/ 16
Sheet 2 of 2
4.02
3232
3135
36
33
34
37
29
27
28
24
18
17
5
23
3
2
3
4
22
11
1
3838
12
141514131621
30
20
19
1098
1
266
25
7
