MODEL M-2B
REPLACEMENT COMPONENT LIST

PowerMate
®
Operation Manua
l
PARTS LIST
DESCRIPTION
PART No.ITEM
TOP GUARD
3024701
SCREW ASSEMBLY300550C
2
ELECTRIC MOTOR
050860D3
BOTTOM RUBBER GUARD
4002304
MOTOR GUARD305770
5
SPLASH GUARD
3057716
SOLID STATE CONTROLLER052810
7
BUZZER ASSEMBLY
3015228
SWITCH PUSH BUTTON0502109
BOTTOM WHEEL AXLE
30782010
WASHER 3/4 SAE05006011
WHEEL 8"30132012
COTTER PIN05011013
FELT STRAP BAR
10196014
FELT TOP10141015
WHEEL CASTER 3"
05133016
DOLLY ATTACHMENT30581017
INNER FRAME
300110C
18
OUTER FRAME300120C19
STEEL ROLLER
05297020
HOOK BAR30073321
STRAPBAR ASSEMBLY400080S
22
BATTERY 12V 32Ah
051310C
23
OUTER FRAME STIFFENER
30300024
FUSE 10 AMP AGC
05170525
BATTERY COVER BOTTOM
30601026
BATTERY COVER TOP306000C
27
CIRCUIT BREAKER 100A05136428
GASKET - CIRCUIT BREAKER
05142529
FUSE HOLDER052690B30
CHARGE PLUG
301393A31
TERMINAL COVER LH MS05131132
TERMINAL COVER RH MS
05131233
PN 010510 Rev.E1
Eng. 03/ 31/ 16
Sheet 1 of 2
4.03
28
29
27
31
30
25
9918
32
33
23
26
1
2
19
20
15
2222
24
14
4 5
3 8
7
6
20
10
11
12
11
13
16
21
17
