2.3.17TheSmartcardfunction
TheSmartcardoperatesasmemoryandcansavethesettingsoftheamplifier. Thesesettingscanbeloadedintoother
amplifiersavoidingthemanualsetupofthese.WhenyouinsertthesmartcardintheslotovertheLCDscreen(see
figure2.3.11),thescreeninthefigure2.3.12appears.
figure2.3.11
contacsonthe
bottomside
back
ok
Loadsettings
Savesettings
Youcanselectthedesiredoptionbypushingupordownbuttonand"ok"toactivateit. Theoption"Loadsettings"does
notappearifthesmartcardisblank.
figure2.3.12
