7.3Technicalspecifications
POWERREQUIREMENTS
Power supply..............................................................................................................................115÷230V(-15%, +15%)
Powerfactor..........................................................................morethan0.95(0.90forK3-K2)from500Wtofullpower
Operating temperature ................................……………...……..................................................................... 0°C,45°C
Weight............................................................................................8Kg(17.6lbs)forK3-K2,12Kg(26.5lbs)allothers
Externaldimensions.........................................Standardrack19"(W),1Units(H),497mm(D),380mm(D)forK3-K2
AUDIO SECTIONS
Bandwith(1W,8Ohm)...................................................................................................................20Hz,20KHz±0,2dB
Dampingfactor(8Ohm).............................................................................................................(20Hz,200Hz)>5000
SlewRate(8Ohm)............................................................................................................50V/uS(inputfilterbypassed)
S/Nratio....................................>110dB(K2),.>112dB(K3),>108(K4),>108(K6),>109(K8),>110(K10),>110(K20)
Distortion THD…………………………………………………..... Max < 0.5% from 1W to full power (typically < 0.05%)
Intermodulation SMPTE …………………………..………...…….Max < 0.5% from 1W to full power (typically < 0.05%)
IntermodulationDIM30................................................................Max<0.5%from1Wtofullpower(typically<0.05%)
Inputs...................................Balancedtoground,XLRfemalecombojack6.3mm;XLRwithparallelonXLR(K3-K2)
Impedance...........................................................................................................10KOhmeachlegbalancedtoground
Gain …………………………………………………………….….…………………...…....26, 29, 32, 35dB,userselectable
Outputs… ………………..…....High currentNeutrik 4-pole Speakon connectors (pins 1+ 2+ paralleled,1-2- paralleled)
OUTPUT SPECIFICATIONS
PowerWATT (EIAJ)
Stereo mode
(1KHz, 1% THD)
FEATURES
2Ohm
8 Ohm
4Ohm
3600
2500
1300
Bridged mono
26
2600
1700
900
K4
9000
5200
2700
K20
K6
K8
K10
4Ohm
16 Ohm
8Ohm
7200
5000
2600
5200
3400
1800
K4
18000
10400
5400
K20
K6
K8
K10
Worldwidemainsoperatingvoltage
PowerFactorCorrection(PFC)
LEDbarindicator
Over-temperatureForecasting
Thermalprotection
Short-Circuitprotection
Over-Load
Outputprotection
Temperaturecontrolledaircoolingsystem
Cliplimiterandpermanentsignallimiter
LCDmatrixinteractivedisplay
Digitalgain-attenuationcontrol
SmartCardmanagement
Userselectablemaximumoutputpower
Userselectablemaximummainscurrentdraw
Remotecontrol-diagnostic
Option DSP/Ethernet
2800
2600
1400
K3
5600
5200
K3
Maxoutputvoltage:
K4
K20
K6
K8
K10
165V
K3
125V
153V
169V
200V
225V
Maxoutputcurrent:
K4
K20
K6
K8
K10
75A
K3
85A
85A
85A
85A
102A
2800
2400
1950
1000
K2
4800
3000
1500
6000
4000
2000
12000
8000
4000
9600
6000
3000
4800
3900
K2
2000
K2
140V
K2
75A
