powersoft Quattrocanali 4804

INDEX
52
QUATTROCANALI | SERVICE MANUAL
QUATTROCANALI No DSP No Dante
Product Code Main Ctrl Front Rear
4804 PF000465 SMD01094.R SM001101.R SM001097.R SM001099.R
2404 PF000464 SMD01095.R SM001101.R SM001097.R SM001099.R
1204 PF000463 SMD01095.R SM001101.R SM001097.R SM001099.R
QUATTROCANALI Yes DSP Yes Dante
Product Code Main DSP + DANTE Front Rear
4804 PF00H465 SMD01094.R SM001107.R SM001097.R SM001099.R
2404 PF00H464 SMD01095.R SM001107.R SM001097.R SM001099.R
1204 PF00H463 SMD01095.R SM001107.R SM001097.R SM001099.R
DUECANALI No DSP No Dante
Product Code Main Ctrl Front Rear
4804 PF000461 SMD01149.R SM001101.R SM001098.R SM001100.R
1604 PF000462 SMD01096.R SM001101.R SM001098.R SM001100.R
0804 PF000460 SMD01096.R SM001101.R SM001098.R SM001100.R
DUECANALI Yes DSP Yes Dante
Product Code Main DSP + DANTE Front Rear
4804 PF00H461 SMD01149.R SM001107.R SM001098.R SM001100.R
1604 PF00H462 SMD01096.R SM001107.R SM001098.R SM001100.R
0804 PF00H460 SMD01096.R SM001107.R SM001098.R SM001100.R
15. Quattrocanali & Duecanali Series Hardware Composition Part Number
16. “Golden Sample” for Authorize Service Center for Toubleshooting
Part Number Model
Control Board SM001101.R
For Quattrocanali & Duecanali
DSP + D Board SM001107.R
Front Board SM001097.R
For Quattrocanali
Rear Board SM001099.R
Front Board SM001098.R
For Duecanali
Rear Board SM001100.R
