Model
1000
Installation and Operation Manual
Page
27
OFFICIAL 6/1/2001
INSTALLATION CHECKLIST
Is the Model 1000 securely mounted in a vertical position (fuses up) [page 9]?
Is there a clear path for airflow through the base heatsink and through the chassis
[page 9]
?
Is the temperature of the air surrounding the drive within specifications
[page 9]
?
Is the AC power source for the drive of the proper voltage, frequency, and capacity
[page 11]
?
Is the motor securely mounted and aligned
[motor manual]
?
Is the drive and motor system properly grounded
[pages 11 and 13]
?
Are the motor leads connected in the proper order
[page 13]
?
Is the cable from the motor to the drive properly connected
[page 13]
?
If an Output Contactor is used, is it properly interlocked
[page15]
?
If Dynamic Braking is used, are the resistors properly installed and wired
[page15]
?
Is the motor thermal properly wired to the drive
[pages 16 and 17]
?
Is the Emergency Stop button properly installed
[pages 16 and 17]
?
Are other drive controls properly wired
[pages 16 and 17]
?
Is the Speed Reference source properly wired in
[page 21 or 23]
?
Is the motor mechanically safe to run (an unloaded motor is recommended) ?
Is the machine safe to run and are all personnel clear ?
Proceed to the Start Up section.
