INSTALLATION:
+ (Load) dry contact
VBAT ≤ VLVD: The (Load) dry contact controls the load ❷ second
disconnection.
VBAT ≤ VLVR: The (Load) dry contact controls the load ❷ second
connection.
CAUTION
The Battery Control Voltage Parameters refer to Operation -
Settings.
WARNING
When the system is power o, the (Utility/Generator) dry contact
OFF interface is closed. Please check the system in time.
Refer to below the diagram:
