18
OPERA
TION:
LCD DISPLAY
1.
Status Description
Name
Symbol
Status
PV array
Day
Night
No charge
Charging
PV array's voltage, current, and generate energy
Battery
Battery capacity, In Char
ging
Battery V
oltage, Current, T
emperature
Battery T
ype
Load
(Load) dry contact connected
(Load) dry contact disconnected
2.
Browse interface
!
IMPORT
ANT
When no operation, the display interface will be an automatic
cycle except for the load time1 and load time 2 interface.
19
