6
GENERAL INFORMATION:
CHARACTERISTICS
Figure 1 Product Characteristics
1 Charging indicator
2 SELECT button
3 External fuse
4 Grounding terminal
5 Screw hole (M4)
6 (PV reverse polarity) alarm
indicator
7 Generator/Load) dry contact
enable switch
1
8 RTS interface
2
9 RS485 port (5VDC/200mA)
3
10 (Utility/Generator) dry contact
ON interface
11 RBVS interface
12 (Load) dry contact interface
5
13 (Utility/Generator) dry contact
OFF interface
14 PV terminals
6
15 Battery terminals
6
16 ENTER button
17 LCD
18 Fault indicator
