powertronics PQR D52 - Operating, Mechanical, and Interface Specs; Operating and Mechanical Specifications; Serial Interface Specifications

PQR Series Model D52
Page 43
www.Powertronics.com
V2.1
Operating Specifications
Temperature: 0 - 50 degrees C
Humidity: 10% to 80% (non condensing)
AC Voltage: 80 - 260 Volts AC
AC Current: 0.1 amp
Line Frequency: 40Hz - 400 Hz
Mechanical Specifications
Weight: 2 pounds
Size: 6" wide x 7" deep, x 1.5" high
Power Cord: 6 feet
Serial Interface Specifications
USB Port USB Connector
RS232 Port: DB9 - RS 232C
Baud Rate: 1200 -19200 (Programmable)
Protocol: 8 Data, 1 Stop, No Parity bit
