3-7-2-6 . Alarm page
This page records and displays the faults and warning events as they occurred in time.
Interface Description
Backup Time Parameter Setting : (Authorized Installation
Personnel Only)
Others :
Batt Groups : Set the number of battery groups ranging from
1 to 6. The default value is 1 group.
Hot Standby Batt Cap : Set the battery capacity such as 7AH, 9AH, 10AH,
Backup Time 12AH, 17AH, 26AH, 40AH, 65AH, 100AH and so on. The
default value is 9AH.
Factor : Calibrate the displayed backup time by adjusting this
Backup Time :
multiplier factor. The formulation is listed below :
Displayed backup time = Original backup time X Multiplier
Batt Groups : 1 factor
Batt Cap : 9AH The value of the default factor is 1.0 and can range from 0.5 to 2.
Factor : 1.0
These parameters are for the battery backup time calculation.
Alarm Info
Fault :
14 : Output Short
Warning :
01 : Bat Open
To Next Page
