ACDEF6000-22-x Compatible External (Extended Run) Battery Cabinet:
Model: E240-22-A Description: Extended Run Battery Cabinet (20 batteries)
ACDEF6000-22 Typical run times with external battery cabinets
BATT CAB Model
E240-22-A
BATT CAB Part number
17888-01R
B
A
T
T
E
R
Y
Voltage (VDC) 240.0 nominal
Battery
12V, 9 Ahr
Flame Retardant, Sealed Lead-Acid
Quantity 20
Recharge Time 9 hours typical to 90% (Single Battery Cabinet, 1A charger)
M
E
C
H
A
N
I
C
A
L
Length in (mm) 17.25 (438)
Height in (mm) 5.14 (131) [3U height]
Depth in (mm) 27.13 (690) [includes 2.75” (70mm) for battery connection cable]
Unit Weight lbs (kg) 142 (64.5)
Shipping Weight lbs (kg) 161 (73.2)
Percent
Capacity
Watts
Number of Battery Cabinets
1 2 3 4 5 6 7 8
Runtimes are expressed in minutes
Typical runtimes based on fully charged, new batteries, operating under typical load conditions
Times estimated assuming a switch mode power supply
Runtimes are affected by battery age, ambient temperature, site specific usage patterns and load conditions
10 540
92 233 402 593 801 >16 hrs >16 hrs >16 hrs
20 1080
46 118 204 301 406 519 639 765
30 1620
30 75 130 192 259 331 408 488
40 2160
21 54 93 137 185 237 291 349
50 2700
16 41 71 105 142 181 223 266
60 3240
13 33 57 84 113 145 178 213
70 3780
11 27 47 69 93 119 147 176
80 4320
9 23 40 58 79 101 124 149
90 4860
8 20 34 50 68 87 107 128
100 5400
7 17 30 44 59 76 93 112
