Powerware 9315 UPS - Figure 5-4. Load Amps Meters Screen

Using the Monitor Panel
5−6
EATON Powerware
®
9315 UPS (200–300 kVA) Operation Manual S 164201036 Rev G www.powerware.com
Uninterruptible Power System
System Normal
Alarm: None
Notice: None
Meters
System
Load Amps
Events Statistics Graphics SetupMeters
Output Current
125%
100%
75%
50%
25%
0%
Phase A Phase B Phase C
04 NOV 1997 14:23:45
Battery
100%
Percent
Figure 5-4. Load Amps Meters Screen
