PowMr POW-M80 Series User Manual

User Manual
POW-M80 & POW-M100 Series
23
6 Specification Parameters
Models
80A
100A
Solar Input Specification
Max. Solar Array Open-Circuit
Voltage
160V
Maximum Input Power:
For 12V System
For 24V System
For 36V System
For 48V System
960W
1920W
2880W
3840W
1200W
2400W
3600W
4800W
Battery Charging Specification
Charging Technology
MPPT
Charging Algorithm
3 Stages
Nominal System Voltage
12V/24V/36V/48V
Battery Voltage Range
9~60V
Rated Charging Current
80A
100A
Maximum Efficiency
≤98%
MPPT Efficiency
>99%
Temperature Compensation
-3mV/℃/2V（default）
Self-Consumption
44mA/12V; 26mA/24V; 18mA/36V; 12mA/48V
Environment Specification
Operating Temperature Range
-35℃~+45℃
Humidity Range
≤95%，Non-condensing
Altitude
<3000m
General Specification
Protection Level
IP32
Dimensions
260x180x75mm
315x195x80mm
Net Weight
2kg
2.7kg
