Powtran PI7500 Series User Manual

Section V. Function parameter table
21
Keypad potentionmeter
FWD/REV set
10
*reserved 11
*reserved 12
Up/Down control mode 2 13
Keypad 0
Keypad + terminal 1
*reserved 2
terminal 3
F05 run control mode
*reserved 4
- 0 Y
Asynchronous space vector
PWM
0
Stepless & subsection
synchronous space vector
PWM
1
F06 waveform mode
2 phase optimized space
vector PWM
2
- 1 N
F07 auto.torque boost 0~10 % 0 Y
F08 V/F boost mode 0~61
-
2 N
F09 accelerate time 0.1~3200.0
s
10.0 Y
F10 decelerate time 0.1~3200.0
s
10.0 Y
F11 slip compensate 0~10 % 0 N
F12 O.P. voltage ratio 50~110 % 100 N
10.00~300.00 F03=0 50.00
F13 max. frequency
100.0~800.0 F03=1
Hz
500.0
N
5.00~ F13 F03=0 50.00
F14 basic frequency
50.0~ F13 F03=1
Hz
500.0
N
F15 carrier frequency 1.0~16.0 kHz ★ Y
0.00~ F17 F03=0 0.00
F16 Lower frequency
0.0~ F17 F03=1
Hz
0.0
N
F03=0 50.00
F17 upper frequency F16~F13
F03=1
Hz
500.0
N
F18 S curve acc. start 0.0~50.0 % 0.0 Y
F19 S curve acc. stop 0.0~50.0 % 0.0 Y
F20 S curve dec. start 0.0~50.0 % 0.0 Y
F21 S curve dec. stop 0.0~50.0 % 0.0 Y
Section V. Function parameter table
22
0.00~ F13 F03=0 0.00
F22 min. running fre.
0.0~ F13 F03=1
Hz
0.0
N
F23 DC brake current 0~135 % 100 Y
F24 start brake time 0.0~60.0 s 0.0 N
F25 stop brake time 0.0~60.0 s 0.0 N
0.00~F13 F03=0 0.00
F26 brake start fre.
0.0~F13 F03=1
Hz
0.0
Y
Deceleration stop 0
F27 stopping mode
Free stop 1
- 0 N
F28 jog acc. time 0.1~3200.0 s 1.0 N
F29 jog dec. time 0.1~3200.0 s 1.0 N
Forward 0
F30 jog direction set
Reverse 1
- 0 N
F03=0 6.00
F31 jog frequency set F16~F17
F03=1
Hz
60.0
Y
F03=0 40.00
F32 traverse fre. 1 F33~F17
F03=1
Hz
400.0
Y
F03=0 20.00
F33 traverse fre. 2 F16~F32
F03=1
Hz
200.0
Y
0.00~5.00 F03=0 2.00
F34 traverse differ.
0.0~50.0 F03=1
Hz
20.0
Y
F35 traverse time T1 0.0~3200.0 s 2.0 Y
F36 traverse time T2 0.0~3200.0 s 2.0 Y
0.00~F13 F03=0 0.00
F37 skip frequency 1
0.0~F13 F03=1
Hz
0.0
Y
0.00~F13 F03=0 0.00
F38 skip frequency 2
0.0~F13 F03=1
Hz
0.0
Y
0.00~F13 F03=0 0.00
F39 skip frequency 3
0.0~F13 F03=1
Hz
0.0
Y
0.00~5.00 F03=0 0.00
F40
skip frequency
range
0.0~50.0 F03=1
Hz
0.0
Y
Invalid 0
Valid 1
F41
auto. Voltage
regulation
Valid but invalid when
decelerating
2
- 0 Y
