Section VII. Fault Diagnosis and Solutions
Disturbance
Check the earthing wire, screened cable
grounding and terminals.
Too much load
Lower the load.or enlarge b01 in the allowable
load range or enlarge F46 to raise the protection
level.
overload
OL
Inappropriate param
set
Modify the parameters of the functions b01.
Power voltage exceeds
the limit
Checking voltage is right or not.
Frequency inverter rated voltage setting is right
or not.
Too fast deceleration Modify the parameters of the functions F10.
Over voltage
OU
The load has too much
inertia
Reduce the load inertia, or raise the capacity of
frequency converter, or use B type converter or
add a braking unit.
Too low power voltage
Checking voltage is right or not.
Frequency inverter rated voltage setting is right
or not.
The power is off
transiently
Add options of capacitor boxes.
Low voltage
LU
The line has too small
capacity or great rush
current exists on the lines.
Make renovation on power supply system.
Too high ambient
temperature
Improve ambient conditions.
Overheat
OH
The carrier frequency is
too high
Check the setting value of function F15.
Note:
※ Switch off the power supply, and do not touch the PCBs and any parts
inside in five minutes after the charging indicator light (！CHARGE)
goes off. Ensure the capacitance has been discharged completely by
measuring with the instrument before work inside. Otherwise, there is
a danger of electric shock.
※ Do not touch the PCB or IGBT and other internal parts unless actions
have been taken to prevent the static electricity. If not, the components
may be damaged.
Section VIII. Standard Specifications
8-1. Specification
Voltage 220V 1Ф 220V (240V)
380V (415V)
(KW) (A) (A) (A)
0.4 2.5 2.5 -
0.75 4 4 2.5
1.5 7 7 3.7
2.2 10 10 5
8-2. Standard specification
items specifications
Voltage and
frequency
Single-phase 200~240V,50/60Hz Three-phase 200~240V,50/60Hz
Three-phase 380~415V,50/60Hz
power
Allowable Fluctuation
range
voltage: ±15% frequency: ±5%
Control system high performance vector control inverter based on DSP
Output frequency G:0.00~800.0Hz,the maximum frequency range is 10.00~800.0Hz
control method V/F control, V/F+ PG control, vector + PG control
waveform produce
methods
asynchronous space vector PWM, step less and subsection synchronous
space vector PWM,2 phase optimized vector PWM
Auto torque boost
function
Realize low frequency (1Hz) and large output torque control under the v/f
control mode.
Accelerate /decelerate
control
Acceleration/Deceleration S curve subsection set mode. The maximum
running time is 26 hours.
Program running control
7 step speed program running, the maximum running time is 88 hours.
frequency setting
accuracy
Digital references:0.01Hz(300 Hz and below),0.1 Hz(above 300 Hz)
Analog references:0.05Hz/60Hz
frequency accuracy Speed control tolerance 0.01%(25℃±10℃)
V/F curve mode Linear,square,8 V/F curve set by user
Over load capability G:150% for one minute, 200% for 0.1 second
control
slip compensation 0~10% automatic slip compensation
running method Keypad/Terminal
frequency setting
There are 10 frequency setting modes, including DC 0~10V,
DC 0~20mA, DC 4~20mA, potentiometer on the keyboard.
start signal forward, reverse
running
Input signal
Multi-segment
speed
can set 7 steps speed at most(using multi-function or program running)
