FRONT AND BACK LAYOUT
Picture 1:FrontofPReview5714.
Picture 2: BackofPReview5714.
PROGRAMMABLE LED INDICATOR
PREVIEW 5714
• 4-digit 14-segment LED indicator
• Input for mA, V, potentiometer, RTD and TC
• 2 relays and analogue output
• Universal voltage supply
• Front key programmable
Application:
• Displayfordigitalreadoutofcurrent,voltage,temperatureorpotentiometer
signals.
• Processcontrolwith2pairsofpotential-freerelaysand/oranalogueoutput.
• Forlocalreadoutinextremelywetatmosphereswithaspeciallydesigned
splash-proof cover.
Technical characteristics:
• 4-digitLEDindicatorwith13.8mm14-segmentcharacters.Max.display
readout-1999...9999withprogrammabledecimalpoint,relayON/OFFindi-
cation.
• Alloperationalparameterscanbeadjustedtoanyapplicationbyuseofthe
front keys.
• PReview5714isavailablefully-configuredacc.tospecificationsreadyfor
process control and visualisation.
• Helptextsineightlanguagescanbeselectedviaamenuitem.
• Inversionswithrelayoutputstheusercanminimisetheinstallationtesttime
by activating / deactivating each relay independently of the input signal.
Mounting:
• Tobemountedinfrontpanel.Theincludedrubberpackingmustbemounted
betweenthepanelcutoutholeandthedisplayfronttoobtainIP65(NEMA4)
tightness.Forextraprotectioninextremeenvironments,PReview5714can
bedeliveredwithaspeiallydesignedsplash-proofcoverasaccessory.

PR electronics 5714 Specifications

General

Brand	PR electronics
Model	5714
Category	Measuring Instruments
Language	English
