PR Lighting PR-2203 XR 200 User Manual

12/20
128-135
Gobo 16
136-143
Gobo 17
144-159
Rotation （From slow to Fast）
160-175
Reverse Rotation （From slow to
Fast）
176-183
Shake 1（From Fast to slow）
184-191
Shake 2 （From Fast to slow）
192-199
Shake 3（From Fast to slow）
200-207
Shake 4（From Fast to slow）
208-215
Shake 5（From Fast to slow）
216-223
Shake 6（From Fast to slow）
224-231
Shake 7（From Fast to slow）
232-239
Shake 8（From Fast to slow）
240-247
Shake 9（From Fast to slow）
248-255
Shake 10（From Fast to slow）
5 5
Prism Wheel
000-063
White
064-127
Prism
128-191
Frost Filter
192-255
CT filter
6 6
Prism Rotation
000-063
Sto
p
064-127
Rotation （From slow to Fas
t
）
128-191
Sto
p
192-255
Reverse Rotation （From slow to
Fast）
7 7
Focusing 000-25
5
Linear Focusing
8
Focusing Fine 000-25
5
Focusing in 16 bit precision
8 9
Pan
000-255
Pan(0°~540°)
10
Pan Fine
000-255
Pan in 16 bit precision
9 11
Tilt
000-255
Tilt(0°~270°)
12
Tilt Fine
000-255
Tilt in 16 bit precision
13
Pan & Tilt
Speeds
000-255
Pan & Tilt Speed from Fast to Slow
10 14
Control
000-031
Reserved
032-063
Lamp Off (stop in DMX value for 2 s)
064-095
Reserved
096-127
Lamp On ( stop in DMX value for 2 s)
128-159
Reserved
160-191
Rese
t
( stop in DMX value for 2 s)
192-255
Reserved
