PR Lighting PR-2203 XR 200 - DMX PROTOCOL

11/20
DMX PROTOCOL
Short
mode
Standard
mode
FUNCTION DMX DESCRIPTION
1 1 Strobe
000-015
Open
016-255
Strobe from Slow to Fas
t
2 2 Dimmer
000-255
From dark to brigh
t
3
3
Color Wheel
000-095
White
096-103
Color 1
104-111
Color 2
112-119
Color 3
120-127
Color 4
128-135
Color 5
136-143
Color 6
144-151
Color 7
152-159
Color 8
160-167
Color
168-175
Color 10
176-183
Color 11
184-191
Color 12
192-199
Color 13
200-207
Color 14
208-223
Rotation （From slow to Fast）
224-239
Stops with White
240-255
Reverse Rotation（From slow to
Fast）
4
4
Fixed Gobo
Wheel
000-07
White
008-015
Gobo 1
016-023
Gobo 2
024-031
Gobo 3
032-039
Gobo 4
040-047
Gobo 5
048-055
Gobo 6
056-063
Gobo 7
064-071
Gobo 8
072-079
Gobo 9
080-087
Gobo 10
088-095
Gobo 11
096-103
Gobo 12
104-111
Gobo 13
112-119
Gobo 14
120-127
Gobo 15
