10/16
192-223 White
224-255 Red & White
3 4 Red 000-255 Linear dimming from dark to bright
4 5 Green 000-255 Linear dimming from dark to bright
5 6 Blue 000-255 Linear dimming from dark to bright
7 Hue 000-255 Hue Options
8 Saturation 000-255 Saturation from light to dark
9 Brightness 000-255 From Dark to Bright
6 10 Strobe
0 Nil
001-255 Strobe speed from slow to fast
7 11
Pan
000-255
Pan 540°
8 12
Pan 16 Bit
000-255 Pan 16 bit Precision Rotation
9 13
Tilt
000-255
Tilt 270°
10 14 Tilt 16 Bit 000-255
Tilt 16 Bit precision rotation
11 15
Pan/Tilt
Speed
000-255 From fast to slow
12 16 Control
000-048 Reserved
049-255 Reset
. INDICATION OF LED DIGITAL TUBE
Decimal point of the first digital tube
On DMX signal OK
Off No DMX signal
Decimal point of the third digital tube
On Master / slave signal is OK
Off No master / slave signal
Decimal point of the fourth digital tube
On When setting master mode
Off When setting slave mode
Parameters that LED digital tubes display Flash Parameters not saved, press “ENTER” to save them
MAINTENANCE
If the Fixture does not function, check if the fuses on the power socket of the unit is broken or not, if broken, they should
only be replaced by fuses of the same specification. Should there be damaged call a qualified technician before
replacement. The fixture has thermal protection device that will switch off the unit in case of overheating. Should any
case like this happen, check if the fans work well or fans and fan screens are blocked, restart the fixture before the
problems have been found and resolved.
Any maintenance work should only be carried out by qualified technicians.
